OVERHEAD LINE

Our Overhead Line products include a large variety of multi-purpose winches, clamps, accessories, poles and auxiliary equipment. If you cannot find what you're looking for, please get in touch and we may be able to assist.

Drum Trailers

The Drum Trailer comes in three versions, and provides a compact and secure method of drum transportation

Drum Cradle

This universal drum handling aid finds use in drum storage yards for lifting drums for cable removal, or on site for pulling out conductors.

Cable Drum Stand

The Drum Stand has been designed in sections for ease of transportation and simply slots together to form a rigid and stable drum stand.

Insulated Connectors

Connector Assemblies are provided as an effective method of joining two cable pulling grips together when pulling O/H conductors.

Triple Weave Single Eye Pulling Stockings Flexible Eye With Shoulders

A selection of different sized pulling stockings with shoulders.

Steel Bellmouths

Manufactured from zinc plated steel, the bellmouth comes in separable halves to guide the cable through the duct to avoid damage to both the cable and duct.

Pole Bogie (LP Tyres) With 1260mm Width

This pole bogie is fitted with low-pressure tyres to reduce land damage to a minimum. Ideally suited for transporting poles across rough terrain or soft ground.

Large Single Sheave Aluminum Suspension Block

Capable of accommodating the larger conductor, this aluminium suspension block has an automatic safety gate and steel frames.

Wire Rope

Designed for use when light, compact grip is desired and where conductor damage is not a factor.

Tandem Aluminium Sheave Block

With an automatic safety gate and steel side frames.

Pole Bogie (Standard Tyres) With 1075mm Width

This pole bogie is fitted with standard tyres to reduce the width. Ideally suited for transporting poles when restricted access is required.

Pole Platforms

CBS Aluminium Pole Platforms for varying situations. All models feature a serrated pole-gripping device and are light in weight and simple to apply.

Grips For Standard Aluminium And Copper Conductors (1.36kg)

The smooth round jaw contour provides maximum contact when used on bare ACSR, aluminium and standard copper conductors.

Cable Pulling Grips (Double Weave & Single Eye)

Cable Pulling Grips are manufactured from high-grade galvanised steel wire, in a double or single weave construction.

Come Along Clamps

Conductor self gripping clamps, including Aerial Bundle Conductor Clamps, Grips for larger conductors, Grips for Standard Aluminium and Copper Conductors and more.

Jointing Grips Triple Weave Pulling Stockings With Connecting Bond (Heavy Duty)

A selection of different sized pulling stockings with connecting bond.

Drum Handling

Includes drum trailers, drum jack and stands and more.

Cable Drum Jacks (8 Ton)

Manufactured in a sturdy steel construction, with heavy-duty Acme screw threads to provide safe lifting. Lift 300mm.

Ground Anchor Set

A sturdy ground anchor designed for use where near horizontal loads are being applied. Fixed by the insertion of eight pins. 3000kg SWL.

Braked Drum Stand (D711 Series)

The CBS D-711 series of Braked Drum Stands have been designed in sections for ease of transportation and are simple to assemble.

Parallel Jaw Grip Hdpe Coated Cable To 1.362 Inch

Securely pulls HDPE-coated cable commonly known as “tree wire”. Innovative high-traction surface grips the cable without damaging the outer jacket.

Braked Drum Stand

The CBS D-684 drum stand is compact in size. Each side is fitted with wheels to allow for easy transportation.

Single Sheave Aluminium Suspension Block

Capable of accommodating the larger conductor, this aluminium suspension block has an automatic safety gate and steel frames. Hole mounted to fit insulator clevis.

Cable Pulling Grips (Single Weave & Single Eye)

Cable Pulling Grips are manufactured from high-grade galvanised steel wire, in a double or single weave construction.

Petrol Capstan Winch

The C-1210-500-1 Petrol Capstan Winch is lightweight at just 8.5kg, thus enabling easy handling and smooth running.

Swivel Pole Platform 2000mm

CBS Aluminium Pole Platforms for varying situations. All models feature a serrated pole gripping device and are light in weight and simple to apply.

Swivel Pole Platform 1500mm

CBS Aluminium Pole Platforms for varying situations. All models feature a serrated pole gripping device and are light in weight and simple to apply.

Tower Erection Winch 5 Tonne

A hydraulic winch designed to provide reliable and safe lifting operations for tower and mast erection for the electricity or telecommunications industries.

Winches

A selection of winches including Bulldog Overhead Line, Hydraulic Universal Winch, Overhead Line Construction Winch and more.

Cable Drum Jack Steady Base

The angular steel construction base, increases the sizes of drums which can be lifted by D-246-7-8 Drum Jacks, with increased stability. Effective height 300mm

Cable Drum Jacks (6 Ton)

Manufactured in a sturdy steel construction, with heavy-duty Acme screw threads to provide safe lifting. Lift 300mm.

Intermediate Running Out Block

Has a split frame and hooks to locate on brackets. The aluminium sheave is mounted on sealed ball bearings. Guide rings protect conductor from damage.

Double Sheave Running Out Block

Designed to be strong but light, suitable for pole work. The aluminium sheaves are mounted on sealed ball bearings for low resistance.

Grips For Standard Aluminium And Copper Conductors (1.70kg)

The smooth round jaw contour provides maximum contact when used on bare ACSR, aluminium and standard copper conductors.

Pole Bogie

Multiple sizes of pole bogie, ideally suited for transporting poles across rough terrain or soft ground

Self Gripping Clamps (17.0 Kg)

Suitable for aluminium, ACSR, steel earth wire, anti-twisting rope and copper conductors.

Grips For Standard Aluminium And Copper Conductors

The smooth round jaw contour provides maximum contact when used on bare ACSR, aluminium and standard copper conductors.

Heavy Duty Pulling Stockings

Includes Triple Weave, Single Eye, Pulling Stockings Flexible Eye with Shoulders and Jointing Grips, Triple Weave, Pulling Stockings with Connecting Bond (Heavy Duty) .

Cable Pulling Grips

A selection of cable pulling grips.

Fused Swivels

Fused swivels are used in applications where the pulling force must not be exceeded.

Cable Pulling Grips (Double Weave & Double Eye)

Cable Pulling Grips are manufactured from high-grade galvanised steel wire, in a double or single weave construction.

Pole Bogie (Standard Tyres) With 500mm Width

This pole bogie is fitted with standard tyres to reduce the width. Ideally suited for transporting poles when restricted access is required.

Grip For Extra High Strength Cable & Conductors

Equipped with chain, toggle and shackle to keep grip from falling off the cable. This grip is for support wire .134 and larger.

Triple Braked Drum Trailer

A uniquely versatile tool, a single operator can independently control the tension of all three conductors.

Overhead Line Construction Winch (3 Tonne Capacity)

Designed to give reliable, flexible winching system to meet all 11/33kV work, together with some 66kV and 132kV maintenance requirements.

Overhead Line Construction Winch (4 Tonne Capacity)

Designed to give reliable, flexible winching system to meet all 11/33kV work, together with some 66kV and 132kV maintenance requirements.

Ball Bearing Swivels

Swivels are essential for effective pulling operations of underground cables and overhead conductors.

Running Out Block

Single sheave aluminium suspension block with an automatic safety gate and steel side frames. Hole mounting c/w shackle.

General Duty Pulling Stockings

Duty pulling stockings with a variety of diameters and flexible eye types.

Single Capstan Winch

The C-1210 Single Capstan Winch has been designed to provide a light and powerful universal winch.

Pole Handling & Auxiliary Equipment

Including Pole Erecting Pikes, Pole Bogies Pole, Platforms and Crossarm Lifter.

Double Weave Single Fleeting Eye And Open Sleeve

Pulling socks or stockings, are indispensable in many different cable pulling applications. Includes Double Weave, Flexible Eye(s).

Single Offset Sheave Running Out Block

This block has the same features as the CBS 687. Single sheave is offset to assist with, fixing conductor to clamp.

Crossarm Lifter

This lightweight Aluminium Crossarm Lifter is ideal for raising even the largest crossarms to ESI 4340 to the top of any pole.

Pole Rotating Lever

The CBS D-2070 Pole Rotating Lever has been designed to adjust the rotational orientation of a vertical wooden pole located in the ground.

Drum Trailer (1300kg)

The C-751-13 Drum Trailer has been designed to provide a compact, manoeuvrable trailer which is capable of handling drums up to 2000mm diameter at 1300kg capacity

Ground Anchor

The screw type ground anchor provides secure anchorage points when operating on site.

Grips For Standard Aluminium And Copper Conductors (3.40kg)

The smooth round jaw contour provides maximum contact when used on bare ACSR, aluminium and standard copper conductors.

Drum Trailer (1630kg)

The C-751-16 Drum Trailer has been designed to provide a compact, manoeuvrable trailer which is capable of handling drums up to 2185mm diameter at 1630kg capacity

Spanometer And Overhead Cable & Rope Measuring Device

This machine has been designed to measure lengths of overhead cables. The unit is hung on the cable and a vertically movable pulley is used to clamp the measuring wheel to the cable.

Hydraulic Drum Jacks

Lightweight hydraulic drum jacks, which are almost indispensable for use in the cable yard.

Grips For Large Conductors

These grips are custom made to individual conductor sizes to ensure maximum contact around the conductor circumference.

Cable Pulling Grips & Swivels & Connectors

Includes cable pulling grips, general duty pulling stockings, heavy duty pulling stockings and more.

Self Gripping Clamps

Suitable for aluminium, ACSR, steel earth wire, anti-twisting rope and copper conductors.

Aerial Bundle Conductor Clamps

Manufactured from high quality materials, the clamps have been specially designed to suit ABC conductors.

Rear Pole Roller Block

Suitable for stringing conductors at the rear of an angle pole.

Drum Trailer (1000kg)

The C-751-10 Drum Trailer has been designed to provide a compact, manoeuvrable trailer secure which is capable of handling drums up to 1800mm diameter at 1000kg capacity

Petrol Capstan Winch

The C-1210-500-1 Petrol Capstan Winch is lightweight at just 8.5kg, thus enabling easy handling and smooth running.

Tower Erection Winch 5 Tonne

A hydraulic winch designed to provide reliable and safe lifting operations for tower and mast erection for the electricity or telecommunications industries.

Cable Drum Jack Steady Base

The angular steel construction base, increases the sizes of drums which can be lifted by D-246-7-8 Drum Jacks, with increased stability. Effective height 300mm

Self Gripping Clamps (17.0 Kg)

Suitable for aluminium, ACSR, steel earth wire, anti-twisting rope and copper conductors.

Overhead Line Construction Winch (3 Tonne Capacity)

Designed to give reliable, flexible winching system to meet all 11/33kV work, together with some 66kV and 132kV maintenance requirements.

Self Gripping Clamps (13.5 Kg)

Suitable for aluminium, ACSR, steel earth wire, anti-twisting rope and copper conductors.

Self Gripping Clamps (13.5 Kg)

Suitable for aluminium, ACSR, steel earth wire, anti-twisting rope and copper conductors.

Cable Drum Jacks (3 Ton)

Manufactured in a sturdy steel construction, with heavy-duty Acme screw threads to provide safe lifting. Lift 300mm.

Cable Drum Spindles

A variety of spindles in different sizes, from 1220mm to 3000mm.

Overhead Line Accessories

Fast, accurate cable splice preparation. The bushing holder, cutter and handy carrying case are sold as one unit. Case contains storage sockets for 11 bushings.

Pole Erecting Pikes

Wooden poles can be safely erected with two people deploying these lightweight pole pikes.

Running Out Blocks

Includes aerial bundle conductor (ABC), single offset sheave running out blocks, cross arm running out blocks and suspension r/o blocks.

Conductor Lifter

Designed to be attached to a cross arm to lift bare conductors out to the insulated pots which then allows the pot to be changed.

Self Gripping Clamps (7.0 Kg)

Suitable for aluminium, ACSR, steel earth wire, anti-twisting rope and copper conductors.

Tower Erection Winch

The TEW25H-01 winch has been designed to comply with all the relevant safety requirements for lifting loads. Two fully automatic, fail safe braking systems are incorporated into the unit.
